Supports New Intel® CoreTM X-series Processor i7-7740X and i5-7640X(4 Cores) only
Supports DDR4-4400+(OC) Memory
DDR4 BOOST: Give your DDR4 memory a performance boost.
TWIN TURBO M.2 and Intel Optane Memory Ready: Running at PCI-E Gen3 x4 maximizes performance for NVMe based SSDs.
Military Class 6: Latest evolution in high quality components for best protection and efficiency
DIGITALL POWER DESIGN: Allowing faster and undistorted delivery to the CPU at pin-point precision
Intel® LAN: Great online experience through hardware design and bandwidth management offering the lowest latency.
EZ DEBUG LED: Easiest way to troubleshoot
Audio Boost 4: Reward your ears with studio grade sound quality for a true HI-FI experience
Dual BIOS: Having 2 physical BIOS chips for easy reset and recovery
MULTI-GPU: With STEEL ARMOR PCI-E slots. Supports 2-Way NVIDIA SLITM and AMD CrossfireTM
| SOCKET 2066 |
| CPU (MAX SUPPORT) X-Series |
| CHIPSET Intel X299 Chipset |
| DDR4 MEMORY Intel Core TM X-series Processors (4 core CPU i7-7740X/i5-7640X) - Dual channel memory support DDR4 4500+(OC)/4400(OC)/4333(OC)/4266(OC)/4200(OC)/4133(OC)/4000(OC)/3866(OC)/3800(OC)/3733(OC)/3600(OC)/3466(OC)/3400(OC)/3333(OC)/3200(OC)/3000(OC)/2933(OC)/2800(OC)/2667/2400/2133 MHz |
| MEMORY CHANNEL Dual |
| DIMM SLOTS 4 |
| MAX MEMORY (GB) 64 |
| PCI-EX16 3 |
| PCI-E GEN Gen3 |
| SATAIII 8 |
| M.2 SLOT 2 |
| RAID 0/1/5/10 |
| TPM (HEADER) 1 |
| LAN 10/100/1000x1 |
| USB 3.1 PORTS (FRONT) 4(Gen1) |
| USB 3.1 PORTS (REAR) 2(Gen2 ,Type A+C), 4(Gen1 Type A) |
| USB 2.0 PORTS (FRONT) 4 |
| USB 2.0 PORTS (REAR) 2 |
| AUDIO PORTS (REAR) Realtek ALC1220 Codec |
| FORM FACTOR m-ATX |
| SLI Y |
| CROSSFIRE Y |
| Item Dimension (L inchxW inchxH inch) 11 x 3 x 11 |
